Plate Heat Exchanger Efficiency with Shell-and-Tube Durability

The BQH series bellows tube instantaneous heat exchanger combines the best features of two popular technologies. The bellows-shaped tube walls create turbulence as fluid flows through them. This turbulence disrupts the laminar flow layer and increases contact between the fluid outside the tube and the tube surface. In steam-to-water operation, the heat transfer coefficient reaches 4,300 to 5,500 Kcal/m²·°C·h. In water-to-water operation, the coefficient ranges from 1,800 to 4,400 Kcal/m²·°C·h. These values are comparable to the performance of plate heat exchangers. Unlike plate units, however, this product does not require gasket replacement every year or two. This helps keep maintenance costs low over the service life of the equipment.

Compact Footprint and Easy Cleaning

The design minimizes the overall size of the equipment. You can save valuable floor space in your mechanical room. Cleaning and maintenance are straightforward. Our factory operates specialized equipment, including bellows tube forming machines, automatic cutting machines, and circumferential welding units. We manufacture all core components in-house. Our company is one of the drafting organizations involved in developing the national industry standard for heat exchangers. We hold dozens of utility model patents covering large bellows tubes and floating coil designs. The BQH model is suitable for heating systems. The BQC model is designed for air conditioning systems. The BQR model is designed for domestic hot water systems. All three models share the same bellows tube core. The differences lie in their connection configurations and flow arrangements. This Bellows Tube Instantaneous Heat Exchanger provides a compact solution for applications where efficient heat transfer and easy maintenance are important.

Material Options and Customization

The shell can be made of carbon steel, carbon steel lined with copper, or stainless steel. The tube bundle uses thin-wall bellows tubes made of copper or stainless steel. We design and manufacture the equipment according to GB/T150 standards. Non-standard custom orders are welcome. If you are uncertain which model is suitable for your application, send us your operating conditions. Our engineering department will select the right unit based on your requirements. Every unit undergoes hydrostatic testing and non-destructive inspection before shipment. The 12-month warranty covers manufacturing defects. Export packaging is customized according to your requirements.

Technical Specifications

Parameter	Value
Equipment Type	Bellows tube instantaneous heat exchanger
Steam-to-Water K-Value	4,300 to 5,500 Kcal/m²·°C·h
Water-to-Water K-Value	1,800 to 4,400 Kcal/m²·°C·h
Suitable Heating Medium	0.2 to 0.4 MPa steam / high-temperature softened hot water
Supply Temperature	≤95°C
Tube Material	Thin-wall bellows copper tube / stainless steel seamless tube / stainless steel welded tube
Shell Material	Carbon steel / carbon steel lined with copper / SUS304 / SUS316L
